Touch Keypad Password Key Access Lock Digital Electronic Security Cabinet Coded Locker L=30mm

01ELECTRONIC DOOR LOCKS

Keyless entry for the modern threshold

A discreet digital sentinel for your front door, this compact lock replaces bulky keys with a silent touch interface. Its slim ABS housing sits flush against the frame, offering a clean, modern line that integrates seamlessly into contemporary interiors without visual clutter.

Designed for households, offices, and shared spaces, it manages access through a simple password system. The indicator light confirms status instantly, while a subtle triple beep alerts you to an incorrect entry, keeping your space secure with minimal effort.

07

About this product

1, Made of ABS material, strong, accuracy, safe and durable. 2, Touch keypad password lock, no keys needed. Cool to use. 3, Factory state: Management password: 1234, default home mode, When the green is unlocked, the indicator light will be on, and if the password is wrong, it will sound 4, Brief appearance, compact design, exquisite and accuracy workmanship. 5, Applicable to agent, school, SPA/sauna bath center, swimming pool, gymnasium,golf course, supermarket, hotel, company, factory, household, business clue etc.

Brief appearance, compact design, exquisite and accuracy workmanship.

Applicable to agent, school, SPA/sauna bath center, swimming pool, gymnasium,golf course, supermarket, hotel, company, factory, household, business clue etc.

Maximum installation thickness: L = 20mm, L = 30mm (Optional)

Enter the correct management password “****+OK” key, the buzzer “di…” a long beep, the unlocking light is always on.

Press the OK button again for more than 2 seconds, the lock flashes, press the OK button again.

Enter the numbers “4, 4” and press the “OK” button, “di..” a long beep.

Press the OK button, the buzzer will beep for a long time, and the lock will be opened and stored. The temporary password is set successfully. After entering the standby state, the light of the electronic lock will flash every 3 seconds.

The temporary password can only be used effectively once, and it will automatically become invalid after use.

Enter the correct management password “+OK” key buzzer “di…” a long beep, the unlocking light is always on.

Press the “OK” button again for more than 2 seconds, the lock flashes, press the OK button again.

Enter the numbers “4, 3” and press the “OK” button, a long beep “di…”.

Enter the correct management password, “OK” button, the buzzer “di…” a long beep, the unlocking light is always on.

Press and hold the OK button again for more than 2 seconds to flash, press the OK button again.

Enable input “4, 2” and press the “OK” button, “di…” a long beep.

Close the input “4, 1” and press the “OK” key “Beep..” a long beep.

When the fake password function is enabled, when entering the password, you can enter garbled codes before and after the correct password to cover up the real password and prevent others from prying into the password.

Please note that the new type and old type of this product will be sent randomly, and make sure you will not mind before ordering.

Specification

Features:

Made of ABS material, strong, accuracy, safe and durable.

Touch keypad password lock, no keys needed. Cool to use.

Specification:

Material: ABS

Package List:

1 x Code Security Lock

2 x Screws

1 x Hex nut

1 x Spring Bolt

1 x Fixed Ring

Instructions:

Enable public mode

Set temporary password

Press the OK button, the unlock indicator flashes.

Enter the 4~15 password to be set.

Turn off public mode

Enable and disable false password function

Note:
