TMC2208 V1.2 Stepper Motor Driver Module Controller Plastic 1.4A 3D Printer Driver Board

$24.99

[Durable Material] Stepper motor driver is made of high quality plastic material, which is durable and can be used for a long time.
[High Efficiency] This stepper motor driver board is noise free operation, highest efficiency and perfect motor torque.
[Drive Module Use Method] Remove the 3 jumper caps under the socket. The module has no subdivision setting. The step value is calculated according to 16…
[Stable Performance] Stepper motor driver module is exquisite in workmanship, stable in performance, and can be used with confidence.
[Current] The current of the stepper motor controller is 1.4A, and the maximum current is 2A, which can meet your various needs.

In stock

Specifications

Dimensions	10 × 7 × 2 cm
Weight	0.15 kg

Delivery & Returns

Delivery is priced by postcode: enter yours at checkout to see the cost.
Sent directly from our Australian warehouse partners.
Usually dispatched within 1-3 business days.
Delivery after dispatch: usually 2-8 business days within Australia, 7-14 business days to New Zealand. Tracking is emailed when it ships.
Change-of-mind returns within 14 days on unopened eligible items (10% restocking fee; you pay return postage). Faulty or wrong items are always put right, free. Returns policy

BENFEI 000439SL 2.5 mm Male to 3.5 mm Female Adapter$18.99

Lightning to 3.5mm Aux Audio Cable Adapter for Car Speaker Headphone Sound System$17.99

mbeat USB 3.0 Gigabit LAN Ethernet Adapter - Black$19.99

Ethernet Wall Plate 4 Port Cat6 Ethernet Cable Wall Plate Adapter$17.99

01PRINTERS & ACCESSORIES

TMC2208 V1.2 Stepper Motor Driver Module Controller

1, [Durable Material] Stepper motor driver is made of high quality plastic material, which is durable and can be used for a long time.

The details

2, [High Efficiency] This stepper motor driver board is noise free operation, highest efficiency and perfect motor torque.

About this product

3, [Drive Module Use Method] Remove the 3 jumper caps under the socket. The module has no subdivision setting. The step value is calculated according to 16 subdivisions. The chip uses a differential algorithm to expand 16 subdivisions to 256 subdivisions.

4, [Stable Performance] Stepper motor driver module is exquisite in workmanship, stable in performance, and can be used with confidence.

5, [Current] The current of the stepper motor controller is 1.4A, and the maximum current is 2A, which can meet your various needs.

Driving current algorithm: i = vref* 1.9/2.5, the default Verf is about 0.65V, so the default current is 1.4A, and the maximum current is 2A

Verf measures Gnd and the voltage at the middle end of the potentiometer

When measuring voltage, be sure not to connect the motor, otherwise the drive will be burnt easily

When measuring the voltage, the power should be turned on, and don’t just connect to the USB for power supply

Item Type: Stepper Motor Driver

Material: Plastic

Weight: Approx. 12g / 0.4oz

Algorithm and adjustment of module drive current

1 x Driver

1 x Module
