SeaSonic 600W Active PFC F0 2U PSU
1x SeaSonic 600W Active PFC F0 2U PSU (SS-600H2U)
Features
- – Specification compliance: Intel EPS12V
- – Forward converter circuit
- – High efficiency and reliability for industrial level
- – Easy swap connector design
- – High reliability ball bearing fan
- – Low ripple & noise
- – Smart & Silent Fan Control (S2FC)
- – Short circuit protection on all outputs
- – Over voltage protection
- – Over power protection
- – 100% hi-pot test
- – 100% burn in, high temperature cycled on/off
- – PFC harmonics compliance: IEC1000-3-2 /EN61000-3-2 standards
- Dimension: L270 x W100 x H70mm (10.6 x 3.9 x 2.7)
- Fan type: 60 x 60mm
- Connectors:Customized modular cables
Electrical Specifications
- – Input frequency
- 50 / 60 Hz
- – Inrush current, cold start
- 100A max.
- – Hold up time, full load
- 16ms. typical
- – Efficiency, 220-240VAC, full load
- 83% typical
- – Efficiency, 100-120VAC, full load
- 80% typical
- – Dielectric withstand, input to frame/ ground
- 1800VAC, 1sec.
- – Dielectric withstand, input to output
- 1800VAC, 1sec.
- – Line regulation
- +/-1% typical
- – Load regulation
- +/-5% typical
- – Cross regulation
- +/-5% typical
- – Ripple / noise
- 1%
- – MTBF, full load
- >100K hours (Excluding the DC fan)
- – Power Factor Correction
- Active PFC 99% typical
- Safety
- CUL, TUV, CB, CCC
- EMC
- CE, FCC
