01SEWAGE PUMPS
Quiet plumbing for difficult spaces
Sometimes the ideal spot for a bathroom defies gravity, tucked away in a basement or garage conversion where standard plumbing struggles to reach. The Protege Shower Plus resolves this tension, allowing fixtures to sit lower than the main drain line without compromising function.
This compact macerator pump handles grey water from a shower tray and wash basin, activating automatically once water reaches a set level. It suits domestic projects requiring discreet, reliable drainage in non-standard locations.
02PERFORMANCE
Quiet power for vertical distance
The 200W copper-wound motor delivers consistent performance while maintaining a noise level between 30 and 40 decibels. This allows the unit to operate unobtrusively in living spaces. It can push water up to eight metres vertically or extend it across 80 metres horizontally, bridging gaps that traditional gravity-fed systems cannot manage.
04OPERATION
Automatic activation and flow
The system requires no manual intervention, activating automatically when water reaches an 8cm start level within the 8-litre tank. A built-in non-return valve prevents backflow, while the rated flow of 100 litres per minute ensures efficient drainage. The unit operates on standard 220-240V power via a 1.7-metre cord with an Australian Standard plug.
05INSTALLATION
Compact footprint and simple setup
Measuring 312 x 143 x 145mm and weighing 4.5kg, the pump fits easily into tight utility spaces or under-floor voids. Installation is straightforward with included foot brackets, screws, and rubber feet that stabilise the unit and dampen vibration. All necessary fittings are provided in the box, streamlining the process for both tradespeople and confident DIYers.
06AT A GLANCE
The key points
- 200W copper-wound motor runs at 30-40dB
- Pumps up to 8 metres vertically or 80 horizontally
- Two 40mm inlets connect shower tray and basin
- 8L tank activates automatically at 8cm water level
- Includes hoses, clamps, plugs and mounting feet
07
About this product
The best spot for a bathroom is sometimes the worst spot for plumbing, or gravity. But thanks to the Proteges wide range of macerator pumps this isnt a problem. You can save a significant amount of expense by connecting a small diameter pipe to an existing system; making it ideal for adding a bathroom or en-suite to basements, garage conversions, granny flats, workshops and rooms with concrete slab floors.
The compact Protege Shower Plus is designed for low water level shower trays and can connect with a wash basin.
The Shower Plus runs quietly thanks to the smooth 200W copper wound motor and rubber feet. It is capable of pumping up to eight metres vertically and 80 metres horizontally.
Connecting the Protege Shower Plus is straightforward with quality instructions and all necessary fittings included. And, best of all, once in place, you can forget about it. Not only is it quiet; it’s automatically activated, too.
Specification
- Brand
- Protege
- Model
- Shower Plus
- Application
- Domestic
- Rated Voltage
- 220-240V, 50Hz
- Power
- 200W
- Motor
- Copper Wound
- Noise level (dB)
- 30-40
- Inlets
- 2x ⌀40mm
- Tank Capacity
- 8L
- Vertical Pumping (Max)
- 8m
- Horizontal Pumping (Max)
- 80m
- Rated Flow
- 100L/min
- Non Return Valve
- Yes
- Water Start Level
- 8cm
- Power Cord Length
- 1.7m
- Power Plug
- Australian Standard
IN THE BOX
- 1 x Protege Macerator
- 2 x Sanitary device inlet hoses
- 2 x Inlet blanking plug caps
- 4 x ⌀32-50mm Inlet hose clamps
- 2 x Foot brackets and screws
- 4 x Rubber feet
- User Manual is accessible online
SIZE WEIGHT
- Product Dimensions (W x L x H)
- 312 x143 x 145mm
- Product Weight
- 4.5kg
- Carton Dimensions (W x L x H)
- 23 x 38 x 24.5cm
- Carton Weight
- 5kg
