Mounted on a garden post or rooftop, this sensor tracks the shifting air with quiet precision. Its slender profile blends into outdoor equipment while capturing subtle changes in wind direction.
Designed for weather stations and monitoring setups, it suits enthusiasts who value accurate data over bulky hardware. The unit translates atmospheric movement into clear digital signals.
02MATERIALS
Robust aluminum alloy construction
The body is forged from aluminum alloy, offering strength without excessive weight. This material choice supports durability against varying weather conditions, ensuring the sensor remains stable through seasonal shifts. The finish resists corrosion, maintaining its appearance and function over time.
04CONNECTIVITY
Seamless RS485 communication
Data flows via an RS485 interface, connecting to a computer through a USB module. The standard 2.5-meter instrument line facilitates easy setup. Output options include current and voltage signals, adapting to various logging systems and display units.
05SPECS
Technical specifications and power
Powered by 12V-24V DC, the unit consumes less than one watt. It operates reliably in humidity up to 100% RH and temperatures between -40°C and 50°C. Protection level IP45 shields internal components from dust and water splashes, ensuring consistent performance outdoors.
06AT A GLANCE
The key points
- Constructed from durable aluminum alloy
- RS485 interface connects to USB module
- Measures 0 to 360 degrees with ±3° accuracy
- Operates in temperatures from -40°C to 50°C
- Includes cable, manual and screw bag
07
Highlights
- For
- Wind direction sensor / weather station
- Communication Method
- RS485 to usb module connected to the computer
- Output form
- current 4~20ma voltage 0~5V 0~10V RS485
- Load capacity
- current type output impedance ≤250Ω Voltage type output impedance ≥1KΩ
- Working environment
- temperature -40 ° C ~ 50 ° C humidity ≤ 100% RH
About this product
1, Adopt Aluminum Alloy material. 2, For wind speed direction sensing. 3, Monitoring Tools for garden. 4, With RS485 interface. 5, Excellent quality and durability.
Please note that the new type and old type of this product will be sent randomly, and make sure you will not mind before ordering.
Specification
Features:
Adopt Aluminum Alloy material.
For wind speed direction sensing.
Monitoring Tools for garden.
With RS485 interface.
Excellent quality and durability.
Specifications:
Material: aluminum alloy
Product Type: Six elements of meteorology
Interface type: RS485
Measuring range: 0 ~ 360 °
Accuracy: ±3°
Starting wind speed: ≤0.5m/s
Power supply mode: DC
Instrument line length: standard: 2.5 meters
Protection level: IP45
Cable grade: temperature grade: 80 ° C
Rated voltage: 300V
Product power consumption: 5.5mW
Wind direction measurement range; 16 orientation
Wind direction measurement accuracy: 1 position
Response time: less than 5 seconds
Baud rate: 9600
Communication port: RS485
Power supply: 12V-24V DC
Power consumption: <1W
Operating temperature: -30-80 ° C
Operating humidity environment: 0-100% RH (15-95% RH)
Size: Approx. 16*23cm/6.3*9.06in
Package List:
1 x Sensor
1 x Cable
1 x User Manual
1 x Screw Bag
