01PACKAGING TAPE
Precision thermal bonding for sensitive electronics
A slender strip of black fibre cloth, this tape sits between the chip and the heatsink, invisible yet essential. It manages the heat that builds up in tight spaces, keeping components cool without adding bulk or electrical noise.
Designed for engineers and builders working on circuit boards, LED displays and TV backlights, it bonds firmly where standard adhesives might fail under thermal stress.
02MATERIALS
Fibre cloth core for structural integrity
The tape uses a fibre cloth base rather than simple film, providing durability and flexibility. This construction supports high viscosity, ensuring the bond remains secure even when the material is stretched during application. The black colour indicates a carbon-rich composition suited for industrial environments.
04SPECIFICATIONS
Versatile widths and substantial roll length
Available in six widths ranging from 5mm to 20mm, the tape accommodates various component sizes. Each roll contains approximately 25 metres of material, sufficient for multiple projects. The packing carton measures 11 x 22 x 33 cm, housing the single roll securely.
APPLICATION
Stability across wide temperature ranges
Rated for long-term exposure at 120°C and short-term peaks of 180°C, the adhesive maintains its grip under significant thermal cycling. This makes it suitable for LED lighting, computer CPUs and GPUs, where temperatures fluctuate rapidly during operation.
AT A GLANCE
The key points
- Fibre cloth core with 1.5 W/m·K thermal conductivity
- Widths from 5mm to 20mm; approx 25m roll length
- Insulated up to 4kV breakdown voltage
- Long-term stability at 120°C; short-term to 180°C
- High viscosity adhesive with stretchable, mark-free finish
About this product
Features: Heat resistance: good thermal conductivity and heat dissipation, strong insulation and thermal conductivity, and a wide of suitable temperature. High viscosity: high-quality tape, strong stickiness and ductility, no worries about the tape not being sticky. Stretchable: The tape can be stretched and no marks remain. Tight winding: high-quality tape, you don’for t have to worry about the confusion of the becoming hollow when you wind it. Application: Suitable for circuit board heat dissipation paste, lamp lighting, LED display, TV backlight paste. Specifications: Material: Fiber Cloth Length: Approx. 25m/82.02ft Width: Approx. 5mm(0.20inch)/8mm(0.31inch)/10mm(0.39inch)/12mm(0.47inch)/15mm(0.59inch)/20mm(0.79inch) Thermal Conductivity: 1.5w/for m.k. Breakdown Voltage: 4kv Long-term Heat Resistance: 120°c Short-term Heat Resistance: 180°c Note: Please allow 1-2cm errors due to manual measurement, make sure that you do not mind before you order. Due to the difference between different monitors, the picture may not reflect the actual color of the item. Package includes: 1 Roll Double Sided Thermal Tape Non Conductive Heatsink Sticky Tape Double Sided Thermal Tape for IC Chipset LED TV & LED Lighting Easy to ApplyDouble Sided Thermal Tape High Heatsink Sticky Tape for Coolers, Heat Sink, LED Strips, Computer CPU, GPUdouble sided thermal tape heatsinksuper strong adhesive non conductive heatsink sticky tape
